BattleCore Optics Module
The BattleCore Optics Module is the front-end emitter assembly for a BattleCore tagger. It carries 1x high-power IR emitter LED and 2x red LEDs for muzzle flash, packaged as a fully integrated, self-contained unit.
Because the module handles its own driving and current regulation, it can be swapped for variants with different output power, beam profiles, current requirements, or emitter types — including, in principle, an actual laser diode or other compatible emitter — without any changes to the Tagger Mainboard. The Tagger Mainboard treats the optics module as a black-box emitter, which keeps the optical front-end completely modular and lets you tune range, eye-safety profile, and visual effects independently of the rest of the system.
Full documentation, design files, and community support available. Licensed under our BattleCore Community Hardware License.
Design files and documentation will be available soon
Specifications
1x high-power IR emitter LED
2x red LEDs for muzzle flash
Self-regulating: handles its own current/driving on-module
Drop-in compatible with the BattleCore Tagger Mainboard
Swappable variants: different outputs, current requirements, or emitter types (including lasers) supported without mainboard changes
Pairs with the BattleCore Optics Lens and Emitter Tube
Documentation & Design Files
Schematics - Coming Soon
PCB Layout Files - Coming Soon
Bill of Materials - Coming Soon
Assembly Guide - Coming Soon
License Information
This hardware design is released under the BattleCore Community Hardware License.
You are free to:
- ✓ Use this design for personal projects
- ✓ Modify and improve the design
- ✓ Operate a paid laser tag service using hardware clearly branded as BattleCore
- ✓ Share modifications with the community under the same license
This license is copyleft — modifications must remain under the same license and Irrelon Software Limited may request a copy. Selling the hardware, kits, assembled units, or any product containing the hardware is not permitted under this license and requires a separate commercial agreement. See the full license for details.
