BattleCore Motherboard
The BattleCore Motherboard is the heart of the BattleCore laser tag system. This open hardware design provides all the core functionality needed to build a professional-grade laser tag system.
Designed with modularity in mind, the motherboard features multiple expansion ports for peripherals, efficient power management, and robust wireless capabilities. All schematics, PCB layouts, and bill of materials are openly available under our open hardware license.
Perfect for makers, developers, and professionals who want to build their own laser tag systems.
Full documentation, design files, and community support available. Licensed under our open hardware license (TBA).
Design files and documentation will be available soon
Specifications
ESP32-S3 Microcontroller
Dual-core processor
WiFi 802.11 b/g/n
Bluetooth 5.0 (LE)
Multiple GPIO expansion ports
IR transmitter/receiver interfaces
Power management system
MicroSD card slot
USB-C programming interface
Operating voltage: 3.3V-5V
Dimensions: TBA
Documentation & Design Files
Schematics - Coming Soon
PCB Layout Files - Coming Soon
Bill of Materials - Coming Soon
Assembly Guide - Coming Soon
Programming Guide - Coming Soon
License Information
This hardware design is released under our Open Hardware License (TBA).
You are free to:
- ✓ Use this design for personal or professional purposes
- ✓ Modify and improve the design
- ✓ Distribute the design files
Please ensure you comply with the license terms and provide attribution when using or modifying this design. Full license terms and conditions are coming soon.
